Lecture 21 - Scaling Data Sources

Scaling Data Sources#

Table of Contents#

• Scaling Data Sources
  • Table of Contents
  • Announcements
  • News
  • Scaling and Performance in General
  • JUG Talk Last Week - Tradeoffs in Modern Architectures
  • Scaling Data Sources
  • Demo - Sharding (plus bonus Code Organization, and Fault Tolerance)
    • Code Organization
    • Fault Tolerance
    • Promises
  • Reading

Announcements#

• Assignment 2 is open and due in
• HackUSU is coming up early next month; it’s a good opportunity to continue working on what you’ve been working on, and meet other SWEs (and business students) in Utah.
• Lucid is having a tech talk about building public APIs and developer platforms on February 28th in TMCB 1170 at 6:00pm. Food and drink will be provided:

Come hear about the technical challenges of building APIs at scale. Lucid Software launched their Developer Platform last fall, allowing developers to build out custom functionality on Lucid’s visual collaboration suite. We now need to consider how to write code that is easy to use internally, and great for external developers to build on top of. Whether it’s taking data from an external system to show that in Lucidchart, building out automation in Lucidspark, or many other use-cases we are actively improving what we can support with our APIs. After diving into some of the deeper technical challenges of building out APIs, we’ll end with perspectives from an engineer who transitioned into product management, who helped lead the success of our API launch.

News#

Scaling and Performance in General#

Before we jump into anything else, I want to be clear – these are all scaling techniques, but you may not need any of the techniques that I’m going to talk about. These are tools I think can be useful in your toolbox for if you do run into scaling problems, and a rough overview of them at that.

Scaling is the idea that as more users use your site, you will need more resources in order to handle those users in a performant way. I’m going to go over two approaches that we’ve already touched loosely on: today, we’ll talk about Services, and next time we’ll talk about Sharding.

JUG Talk Last Week - Tradeoffs in Modern Architectures#

• BUILD MONOLITHS! Monoliths keep things simple and easy to maintain and deploy.
• Monolith vs Distributed doesn’t make sense anymore – most things are distributed now.
• Architecture decisions should come down to two things: Functional and Non-Functional requirements.
• Functional Requirements are the features you want to deliver:
  • Ex: I want users to be able to track notes on my site.
• Non-Functional Requirements are how you want to deliver those things:
  • Security, Scalability, Portability, Upgradability, Configurability, Auditability, Traceability, Observability, Testability, Accessibility, etc.
  • These things will determine how you build what you build.
• Non-Functional Requirements tend to be mutually exclusive to a degree, so you should rank them by importance
  • Ex: High scalability at the same time as High performance is hard; in creating scale, you generally introduce additional layers and overhead, which add delays to completing things quickly.

Scaling Data Sources#

We’ll be working in this document today.

Demo - Sharding (plus bonus Code Organization, and Fault Tolerance)#

We’ll be working out of this repo.

Code Organization#

It’s very easy to write code that does what it’s supposed to right in its entrypoint; a tRPC route that handles everything, or a REST endpoint that parses, does a lookup in the database, and returns.

While that works, often times it’s better to separate that logic out. Two reasons for this:

1. It makes it easy to reuse that logic elsewhere; if you need to do SSR, you can reuse the same query and build a page off of that logic, or you can use that query as a building block in more complex logic.
2. It makes it easier to test that logic in isolation, or mock that logic in isolation. I can replace my fancy DB sharding code with a simple JSON store while running tests, and then I don’t need to worry about running a full database (or more than one database) at once.

I propose a model like this:

1
📁 app
2
  📁 src
3
    📁 model -- split logic from other places in the code that make sense to share
4
    📁 db -- database code
5
      📁 repository
6
      📄 userrepository.ts
7
      📄 noterepository.ts
8
    📄 shardmanager.ts
9
    📁 routes -- rest-related endpoints
10
      📁 middleware
11
        📄 authenticator.ts
12
      📁 user
13
        📄 registerhandler.ts
14
      📁 notes
15
        📄 notelisthandler.ts
16
        📄 notecreatehandler.ts
17
  📄 index.ts -- library entrypoint
18
  📄 app.ts -- actual app code

DI can be really useful here, especially with autowiring (automatically constructing required classes, and sending them to the class’ constructor). Then you don’t need to worry about manually creating these classes. We’ll do a more formal lecture on this in the future, but this has come up a couple times recently so I wanted to touch on it here.

Fault Tolerance#

This video on the event loop might be useful to review here, especially around the fault tolerance portion, and promises are going to be used and abused in this portion.

The idea with fault tolerance is that certain classes of errors are accounted for and mitigated; for example, if I turn my database off, I want to hold any responses for a time and see if trying again a little later will work.

Promises#

The way things used to work, we would just call a callback after some work was completed:

1
readFromFileSystem("myFile.txt", function (file) {
2
  // do something with the file
3
});

However, this quickly gets unweildy when you want to do many things one after the other:

1
readFromFileSystem("myFile.txt", function (file) {
2
  writeToFileSystem("copy.txt", file.contents, function (newFile) {
3
    sendOverNetwork("copy.txt", function (response) {
4
      // Yikes, this is a lot of nesting.
5
    });
6
  });
7
});

So that idea of a callback was abstracted into what’s called a Promise. It contains two things: a function to call when some work is done, and a function to call when something goes wrong. These are normally called resolve and reject:

1
const myPromise = new Promise((resolve, reject) => {
2
  // some code to do something that takes a long time
3
  // ...
4

5
  resolve(result);
6
});
7

8
myPromise
9
  .then((result) => {
10
    // do something with the result
11
  })
12
  .catch((err) => {
13
    // do something to handle an error
14
  });

And syntax sugar was introduced around those to make it deal with these similar to how normal code works, one thing after another:

1
try {
2
  const result = await myPromise; // Does the same thing as above, inside the then block
3
} catch (err) {
4
  // do something to handle an error, just like the catch block above.
5
}

Reading#

None! Next time is a Q&A session. Please add questions to the form, slack them to me, or bring them to class.
